Preservation of pancreatic endocrine and peri-islet exocrine capillary networks in type 2 diabetes
Alex M. Tollefson, Frank R. Marsico, Manami Hara
Alex M. Tollefson, Frank R. Marsico, Manami Hara
View: Text | PDF
Research Article Endocrinology Vascular biology

Preservation of pancreatic endocrine and peri-islet exocrine capillary networks in type 2 diabetes

  • Text
  • PDF
Abstract

Chronic hyperglycemia induces microvascular complications in patients with type 2 diabetes (T2D), particularly diabetic retinopathy, nephropathy, and neuropathy. We revisited the pancreatic vasculature to reexamine such damage in 3D. Using thick pancreatic tissue slices, we analyzed volumetric intraislet capillary density (vICD) and peri-islet volumetric exocrine capillary density (vECD) as well as interface capillary counts along the islet periphery to quantify vascular integration between the islets and surrounding acinar cells. Contrary to the previous reports, vICD was not homogeneous but highly heterogeneous across the five species studied (human, monkey, pig, ferret, and mouse), especially in smaller islets. vICD became less variable with increasing islet size, converging at approximately 20%. With this foundation of islet vascularization, pancreatic tissues from non-diabetic and T2D subjects consisting of 8 age- and sex-matched pairs (age range of 35–65 years with various duration: 0–15 years) were examined. Strikingly, no significant differences in microvascular density were found; mean vICD and mean vECD were nearly equivalent between the groups. Capillary integration with respect to islet size was comparable. These findings suggest that integrated pancreatic blood flow with robust crosstalk between the endocrine and exocrine pancreas may facilitate microvascular preservation in T2D via local distribution of insulin.

Authors

Alex M. Tollefson, Frank R. Marsico, Manami Hara

×

Figure 2

3D reconstruction of islets and their microvasculature.

Options: View larger image (or click on image) Download as PowerPoint
3D reconstruction of islets and their microvasculature.
(A) Top-down 3D ...
(A) Top-down 3D fluorescent view of a region of 50 μm depth. Islet cell marker (HPi1; cyan), CD31 (red). Scale bar: 50 μm. (B) Islet and vasculature generated as 3D surfaces. (C) Compressed top-down 3D view of rendered capillaries. (D) Rendered capillaries isolated at the islet periphery. (E) Workflow of vICD measurement. Large-scale view of a specimen. Scale bar: 600 μm. (F) Fluorescent image. (G) Islets with intraislet capillary fluorescence isolated. (H) Intraislet vasculature generated as 3D surfaces. (I) Binary fluorescence masked to rendered structures and later used for vICD determination. Scale bar: 100 μm.
